smoke sensor

This product, sometimes known as a detector, is a photoelectric smoke and temperature integrated detector.The product has a unique construction and employs an MCU to handle the optical signal intelligently. It has anti-light interference, dust and insect resistance, and other features built into the design.Make sure the product is stable. This product can be seen to slow open combustion or smoldering. Smoke reacts more effectively. An internal temperature sensor and photoelectric smoke sensor are features of this product. When the outside temperature rises above roughly 57 °C or the surrounding smoke reaches The product is appropriate for all smoke monitoring applications, including residential, industrial, hotel, business, educational, bank, library, and warehouse settings. The detector emits an alert sound in response to the alarm concentration.

Categories:

Features

MCU automatic processing technology, improve product stability temperature sensor + smoke sensor

  • Fault self-test function
  • Low voltage prompt
  • Automatic reset
  • Infrared photoelectric sensor
  • Sound and light alarm /LED indicator alarm
  • SMT process manufacturing, strong stability
  • Dust-proof, insect-proof, anti-white light interference design
  • Relay switching signal output (normally open, normally closed optional)
Product NameSmoking sensor for monitor smart PDU
Model No.GW-2300S
Size78*17mm
Standby Current16mA (Relay off )3A(Relay on)
Voltage9V-35V
Alarm Current8mA(Relay off)19mA(Relay on)
Alarm IndicatorRed LED indicator
SensorInfrared light sensor
Working Temperature-10°C-+50°C
Environment HumidityMax.95%RH
RF10MHz-1GHz 20V/m
Alarm OutputOn/off to select ,contact rating DC28V100mA
ResetAuto reset/power reset
OEM/ODMYes
Packing50pcs/CTN size:510*340*240MM 12KGS/CTN

Notes

The fault self-detection function of this product is only available for infrared photoelectric sensors Fault detection and low power detection, sensor sensitivity still needs to be improved as required Line test, must be done every month to simulate smoke test, to ensure that the detector is positive Often used.

In order to ensure the smoke sensitivity of the product, every 1 month need to use soft wool.

Before cleaning the detector surface, disconnect the power supply, clean and enter the smoke compartment Clean, and ensure that the simulated smoke test is normal after re-energizing before use. In case of product failure, please contact the supplier in time Contact, do not disassemble and repair without permission, so as to avoid accidents.

If it is not used for a long time, the detector must be removed and put into the packaging box.

Store in a dry and ventilated place.

Smoke detectors can reduce disasters, but they don’t guarantee them Nothing is lost. For your safety, please use this product correctly while in Japan Often in life should be put on the same alert, strengthen the awareness of safety and prevention.

Support

Optional Toolless Installation

Customized shell colors available
