Features
HEAVY DUTY METAL POWER STRIP: Made of rugged Aluminum shell that offers great impact resistant performance, high wear resistance heavy duty power cord protects circuits from fire, impact or rust, and prevents dents and scratches.
24 OUTLET PDU: Providing enough sockets for your data centre cabinet racks. Heavy duty power strip was connected with3M 5G6mm power cord, high current, Max.50Hz/250V/32Amp/24KW.
Detachable mounting ears, reversible ears faces front or back in PDU. Mounting flanges at rear of the PDU, which provide possibility of versatile installation.
OVERLOAD PROTECTOR: With overload protection, the reliable overload switch will trip off automatically to protect your devices when over-voltage, over-current, overload, high-temperature, short-circuiting.
IEC Outlets with locking system: YOSUN reliable locking IEC C13/C19 outlets ensure strong and firm power connection in usage to avoid inserted plugs coming off.
advantage of 2x1P 16A MCB PDU
As the key highlight, the 2x1P 16A MCB PDU offers independent branch protection, ensuring segmented load control that enhances system reliability during varied device operations. Its dual-channel 1P 16A configuration maintains balanced current allocation across equipment clusters, reducing overload risks in demanding rack layouts. With precise protection behavior and high-sensitivity switch response, this YOSUN 2x1P 16A MCB PDU supplier solution supports efficient maintenance and stable long-term operation.
other advantages
- The single phase 32A MCB PDU provides high-capacity current handling with consistent thermal stability for dense server deployments.
- The 20 C13 4 C19 power strip supports mixed-device compatibility, enabling flexible power distribution for both standard and high-power servers via diverse outlet types.
Details
1)Size: 1294*44.8*45mm
2)Color: black
3)Outlets: 20* locking IEC60320C13+4* locking IEC60320 C19
4)Outlets Plastic Material: anti flaming PC module IEC
5)Housing material: 1U Aluminium alloy
6)Feature:2P 16A circuit breaker
7)Amps:32A/customized
8)voltage:230V
9)Plug: IEC60309 (32A 250VAC 2P+E) / IP44 /OEM
10)Cable spec: 3G6mm2,3M/ custom
Support
Optional Toolless Installation
Customized shell colors available
