APC 1U rack PDU features you never knew

You may know the most popular APC 1U rack PDU models like AP7900B, AP7920B, AP7552, AP9560, AP9562, AP9563, and NBYOSUN. Each apc 1u rack pdu brings unique options to your rack setup. Some models include 4-in-1 combination outlets or color-coded connections for easy management. You can find PDUs with live swap network modules and high metering accuracy, making them stand out in data centers. These features often go unnoticed, but they help you choose the right pdu for your needs.

Key Takeaways

• APC 1U rack PDUs come in various models with unique features like remote outlet control, advanced power monitoring, and flexible mounting options to fit different rack needs.
• Remote management lets you control and monitor power use from anywhere, helping you save energy, prevent overloads, and reduce downtime.
• Environmental sensors for temperature, humidity, and leaks protect your equipment by alerting you to potential problems before they cause damage.
• Choosing the right PDU depends on your power needs, budget, and desired features like redundancy, detailed monitoring, or simple power distribution.
• Advanced security features keep your power system safe by controlling user access and protecting data during remote management.

APC 1U Rack PDU Quick Comparison Table

Side-by-Side Model Features

When you look for the right apc 1u rack pdu, you want to see how each model stacks up. The table below shows the main features side by side. You can quickly compare power capacity, outlet type, and management options. This helps you choose the best pdu for your rack.

Tip: You can use this table to match your needs with the right pdu. If you want simple power, the Basic model works well. If you need remote control or detailed monitoring, look at the Switched or Metered-by-Outlet models.

Each pdu in the table offers something different. Some give you basic power distribution. Others let you monitor power use or control outlets from far away. You can find a model that fits your rack and your management style.

APC 1U Rack PDU Model-by-Model Breakdown

AP7900B Overview and Unique Features

When you look at the AP7900B, you see a model designed for control and flexibility. This unit gives you eight NEMA 5-15R outlets. You can control each outlet by itself, which means you can turn devices on or off from anywhere. The AP7900B supports a 15A input current at 120V AC and has a power rating of 1440VA. You get real-time current monitoring and can set alarms to warn you if something goes wrong.

Here is a quick look at what makes the AP7900B stand out:

Tip: You can use the AP7900B to manage power for each device in your rack. This helps you save energy and keep your equipment safe.

AP7920B Overview and Unique Features

The AP7920B brings new technology and better security to your rack. This model gives you gigabit Ethernet connectivity, which means faster network speeds. You get improved cybersecurity with secure interfaces and password policies. The AP7920B lets you manage your PDU from anywhere using web or SNMP interfaces.

You can set up to four user access levels, so only the right people can make changes. The AP7920B works with EcoStruxure IT, which helps you monitor your whole data center. You can set alarm thresholds to prevent overloads. Group outlets together for easy power sequencing. You can even manage more than one PDU from a single IP address, making your network simpler.

Here is a table showing the most important improvements:

Note: The AP7920B is a smart choice if you want strong security, fast network management, and easy control of your rack devices.

AP7552 Overview and Unique Features

The AP7552 is different from the other models because it uses a zero U form factor. This means you can mount it vertically in your rack without taking up any rack space. You get 20 C13 and 4 C19 outlets, so you can power many devices at once. The AP7552 supports a 16A current rating and 230V input, giving you a power capacity of 3680 watts. The 10-foot cord gives you flexibility for installation.

This model works best in data centers or server rooms where you need to power lots of equipment but want to save space. The vertical mounting design lets you use every inch of your rack for servers and other devices.

Here are the main technical specifications:

If you want to maximize rack space and power many devices, the AP7552 is a great option. You can install it quickly and keep your rack organized.

AP9560 Overview and Unique Features

You can rely on the AP9560 when you need a powerful and flexible solution for your rack. This model stands out among APC 1U rack PDUs because it offers a higher current capacity and a unique mounting design. You get a 1U horizontal rack-mountable unit, but you can also mount it vertically in the rear channel of your rack without using tools. This makes installation quick and easy.

Here is a table that highlights what makes the AP9560 different from other models:

Tip: If you need a PDU that handles higher loads and offers flexible mounting, the AP9560 gives you both power and convenience.

AP9562 Overview and Unique Features

The AP9562 gives you a simple and reliable way to distribute power in your rack. You can use this model in small to medium server rooms, branch offices, or even educational labs. It fits into a 1U horizontal rack space and comes with ten standard NEMA 5-15R outlets. The AP9562 uses a standard 15-amp, 120-volt input, which makes it easy to connect in most North American environments.

Check out the main specifications in the table below:

Note: The AP9562 works well when you want a cost-effective and dependable PDU for basic power needs.

AP9563 Overview and Unique Features

You can choose the AP9563 if you want more control and safety in your data center. This model supports real-time monitoring, which helps you spot power overloads before they cause problems. You can manage power to each server component remotely, making it easier to keep your equipment running smoothly. The AP9563 also helps you balance energy use, which can lower your total costs.

You get a local current monitoring display, so you always know how much power your rack uses. Alarm thresholds warn you when power usage gets too high, keeping your equipment safe. The AP9563 meets international safety and performance standards, including ISO9001, CE, and UL. You can customize the outlet configuration and current capacity to fit your needs. This model also offers cost-effective pricing for large data centers and provides strong customer support for installation and troubleshooting.

• Real-time monitoring alerts you to potential overloads.
• Remote management lets you control power to individual devices.
• Energy optimization helps you make smart load balancing decisions.
• Local current display gives you instant power usage information.
• Alarm thresholds improve safety and reliability.
• International certifications ensure quality and safety.
• Customizable options fit your specific requirements.
• Bulk pricing supports large-scale deployments.
• Reliable customer support assists you before and after purchase.
• Fast, transparent global shipping keeps your project on schedule.

The AP9563 fits into a 1U rack space and supports 20A at 120V, making it a strong choice for typical server rack power distribution. You can integrate it with APC’s management software and accessories for a complete power solution.

NBYOSUN Overview and Unique Features

When you look for a rack PDU that gives you more control and flexibility, the NBYOSUN 1U rack PDU stands out. You get advanced intelligent power management features that help you manage your IT equipment with ease. The NBYOSUN model lets you monitor and control each outlet from a distance. You can turn devices on or off without being in the server room. This makes your work easier and helps you respond quickly to any issue.

One of the best features is the rotatable LCD screen. You can see important power information from any angle. The screen shows you real-time data, so you always know how much power your devices use. You can also set up customizable power sequencing. This means you can decide the order in which your devices turn on. You prevent power surges and keep your equipment safe.

NBYOSUN gives you strong safety features. The built-in 16A circuit breaker protects your devices from overloads. If too much power flows through the PDU, the breaker stops it. You keep your equipment safe and avoid downtime.

You can connect to the NBYOSUN PDU using different communication protocols. The PDU supports RS485, SNMP, and HTTP. You choose the protocol that fits your network. This makes the PDU easy to add to your existing systems. You can manage your power from a web browser or through your network management software.

Tip: You can use the NBYOSUN PDU in many places. It fits well in small to medium IT rooms, edge computing setups, and even large data centers. You can mount it horizontally or vertically, so it works in tight spaces or high-density racks.

Here is a table that highlights what makes the NBYOSUN 1U rack PDU unique:

You can deploy NBYOSUN PDUs in many scenarios:

• Small to medium IT environments where you need reliable power and easy management.
• Edge computing setups that require compact and flexible power solutions.
• Large-scale data centers that need scalable, high-performance power distribution.
• High-density racks where space-saving vertical mounting is important.
• Cabinets that demand three-phase power and redundancy for mission-critical systems.

NBYOSUN gives you a high level of customization and performance. You get the tools to manage your power, protect your equipment, and keep your IT environment running smoothly.

Hidden or Overlooked APC PDU Features

Advanced Power Monitoring

You can get more from your APC PDU than just basic power delivery. Many models offer advanced power monitoring features that help you manage your rack better.

• Real-time power monitoring lets you see voltage, amperage, and energy use. This helps you balance loads and avoid overloads.
• Outlet-level monitoring shows you exactly how much power each device uses.
• You can set alarm thresholds. The PDU warns you with network or visual alerts if you get close to an overload.
• Local current displays and load indicator LEDs give you instant feedback during installation or use.
• Remote management works through web, SNMP, or CLI interfaces. You can check and control your PDU from anywhere.
• Firmware upgrades happen over the network, so you keep your PDU up to date without swapping hardware.
• Integration with StruxureWare Data Center Expert lets you monitor and get alerts for your whole setup in one place.

These features help you prevent power problems, plan for growth, and keep your IT equipment safe.

Outlet-Level Switching and Control

A switched rack pdu gives you more control over your devices. You can turn outlets on or off from your desk or even from home. This makes it easy to reboot equipment or stop power to a device that is not working right.
Here is a table showing how these features help you manage your rack:

A switched rack pdu helps you keep your rack running smoothly and safely.

Environmental Sensor Integration

You can add environmental sensors to many APC PDU models. These sensors help you watch for heat, humidity, leaks, or open doors.

• Most advanced PDUs have two sensor ports for temperature, humidity, or leak sensors.
• You can connect up to six sensors using an expansion hub.
• Supported sensors include temperature, temperature/humidity, rope leak detection, and door contact switches.
• The PDU keeps sensors working and alarms active, even if power is lost.

With these sensors, you can spot problems early and protect your equipment from damage. You get alerts if the room gets too hot or if there is a water leak. This helps you keep your data center safe and running well.

Network and Remote Management Capabilities

You can manage your rack power from anywhere with the network and remote management features in APC 1U rack PDUs. These features help you keep your equipment running smoothly and safely. You get several ways to connect and control your PDU:

• Access your PDU using a web browser, SNMP, or Telnet. This lets you check and change settings without being in the server room.
• Control each outlet remotely. You can turn devices on or off, reboot equipment, or set up power sequencing.
• See warning lights and digital displays that show you if your rack is using too much power.
• Set alarm thresholds. The PDU will alert you with lights or network messages if you get close to an overload.
• Upgrade your PDU’s firmware over the network. You do not need to replace hardware to get new features.
• Integrate your PDU with StruxureWare Data Center Expert. This gives you a single place to monitor all your alerts and infrastructure.

Here is a table that shows some of these features:

Tip: With these tools, you can manage your apc pdu from your desk or even from home. This saves you time and helps you fix problems quickly.

Redundancy and Failover Options

You want your equipment to stay on, even if something goes wrong with the power. APC 1U rack PDUs offer strong redundancy and failover features to help you reach this goal.

• Some models support dual power inputs. If one power source fails, the other keeps your devices running.
• Automatic Transfer Switching (ATS) units switch between main and backup power in less than 10 milliseconds. Your equipment does not lose power.
• Advanced voltage sensors watch the power supply. If the voltage drops or spikes, the PDU switches to a safer source right away.
• Rugged relays and switches handle high loads. This keeps power stable and reliable.
• Power-out LED indicators show you the status at a glance.
• You can manage and check these features remotely using a web interface or Telnet.

These features help you avoid downtime and keep your data center or server room reliable.

Security and Access Controls

Protecting your power equipment is important. APC 1U rack PDUs include several security and access control features to keep your system safe.

• You get an easy-to-use web interface that makes secure management simple.
• Encryption keeps your data safe when you manage your PDU remotely.
• You can control who gets access, so only the right people can make changes.

Note: These security features help you keep your power system safe from unauthorized changes or attacks.

Choosing the Right APC 1U Rack PDU Model

Selecting the right APC 1U rack PDU model can help you keep your data center running smoothly. You need to think about your power needs, the type of equipment you use, and the features that matter most for your setup. Reliable power distribution helps prevent shutdowns and equipment failures. Advanced features like load balancing, real-time monitoring, and remote management make your work easier and improve uptime. Certifications and strong vendor support also help you adapt to future needs.

For Remote Management Needs

If you want to control your rack power from anywhere, you should look for models with strong remote management features. These models let you turn outlets on or off, monitor power use, and set alarms without being in the server room. The APC Switched Rack PDU and the APC Metered-by-Outlet with Switching Rack PDU stand out for remote management. They offer:

• Remote outlet switching and control
• Power-on sequencing for safe device startup
• Real-time monitoring and user-defined alarms
• Network management through Web, SNMP, and CLI

These features help you manage servers, switches, and network devices from your desk or even from home.

For Redundancy and High Availability

You need redundancy if your environment cannot afford downtime. Some APC 1U rack PDU models support dual power inputs and automatic transfer switches. These features keep your equipment running even if one power source fails. Advanced models include live swap network cards and dual Ethernet ports for network redundancy. You can also cascade multiple PDUs for extra reliability.

These options help you maintain high availability in mission-critical deployments.

For Detailed Power Monitoring

If you want to track energy use closely, choose a model with detailed power monitoring. The APC Metered-by-Outlet Rack PDU and the APC Metered-by-Outlet with Switching PDU provide per-outlet monitoring. You can see how much power each device uses and get energy usage reports. These models also support environmental sensors and remote management.

• Per-outlet power monitoring for precise energy tracking
• Energy usage reports for better planning
• Environmental sensors for temperature and humidity
• Remote management for easy access

These features help you optimize energy use and prevent overloads in your rack.

For Budget-Conscious Deployments

You want to save money while keeping your IT equipment safe. APC offers rack PDUs that fit tight budgets and still deliver reliable power. The APC AP9562 stands out as a smart choice for budget-conscious deployments. This model gives you basic power distribution without extra features that raise the price. You get a sturdy unit that works well in small or medium server rooms.

Here is a quick look at the APC AP9562:

You do not get advanced monitoring or remote management with this model. Instead, you get a simple, strong PDU that does its job. The AP9562 helps you keep costs low while making sure your equipment gets steady power. You can install it quickly with the included toolless mounting kit. This model works best when you need basic power for servers, switches, or lab equipment.

Tip: If you want more features like power monitoring or remote control, APC has advanced PDUs. These models cost more but offer real-time tracking, per-outlet metering, and remote management. You can choose what fits your needs and budget.

For Environmental Monitoring

You need to keep your IT equipment safe from heat, humidity, and leaks. Many APC 1U rack PDUs support environmental monitoring. You can add sensors to track temperature, humidity, and even water leaks. These sensors help you spot problems before they damage your equipment.

Some advanced PDUs let you connect multiple sensors. You can see real-time data on the PDU’s display or through your network. If something goes wrong, the PDU sends you an alert. This helps you act fast and avoid downtime.

• Temperature sensors warn you if your rack gets too hot.
• Humidity sensors help you prevent moisture problems.
• Leak sensors catch water before it reaches your devices.
• Door sensors tell you if someone opens your rack.

You can use these features to keep your data center safe and running smoothly. Environmental monitoring gives you peace of mind and helps you protect your investment.

Note: When you choose a PDU, check if it supports the sensors you need. This makes it easier to upgrade your monitoring as your needs grow.

Understanding the unique features in APC 1U rack PDUs helps you make smarter choices for your rack. You can pick a model that matches your needs and supports your equipment.

When you know about advanced options like remote management or environmental sensors, you improve efficiency and reliability.

• Explore all features before you buy.
• Use hidden capabilities to manage your rack better.
• Choose the right PDU for your setup and future needs.

FAQ

What is the main difference between a basic and a switched APC 1U rack PDU?

A basic PDU only distributes power. A switched PDU lets you turn outlets on or off remotely. You can control devices from your desk or home.

Can you install an APC 1U rack PDU by yourself?

Yes, you can install it yourself. Most models come with mounting brackets and a user guide. You only need simple tools.

Do APC 1U rack PDUs support environmental sensors?

Many advanced APC 1U rack PDUs support temperature, humidity, and leak sensors. You can connect these sensors to monitor your rack environment and get alerts.

How do you monitor power usage on an APC 1U rack PDU?

You can use the built-in LCD display or connect through a web browser. Some models also support SNMP for network monitoring. This helps you track power use in real time.
